Comparison · Excavator
Caterpillar 320 vs Volvo EC380E
The Volvo EC380E is about 73% heavier than the Caterpillar 320 (39,000 vs 22,500 kg), which usually means more stability and lifting capacity but higher transport weight.
The Volvo EC380E has about 84% more engine power (223 kW (299 hp) vs 121 kW (162 hp)).
Beyond the numbers, compare local dealer support, parts availability and resale value for Caterpillar and Volvo Construction Equipment in your region: over the life of a machine they often matter more than small specification differences.
|
|
|
|---|---|---|
| Operating weight | 22,500 kg (49,600 lb) | 39,000 kg (86,000 lb) |
| Engine power | 121 kW (162 hp) | 223 kW (299 hp) |
| Net power | ≈121 kW (162 hp) | ≈223 kW (299 hp) |
| Max. digging depth | ≈6.7 m (22 ft) | — |
| Engine | Cat C7.1 | — |
| Max. reach at ground level | ≈9.9 m (32 ft 6 in) | — |
| Bucket capacity | 0.9–1.5 m³ (1.2–2.0 yd³) | — |
| Fuel tank | ≈345 L (91 US gal) | — |
| Emissions | EPA Tier 4 Final / EU Stage V | — |
| Strengths |
|
|
| Watch-outs |
|
|
| Full 320 review | Full EC380E review |
Specifications are typical figures for standard configurations and may be measured differently by each manufacturer (for example net vs gross power). Always confirm with the manufacturer or dealer. Build another comparison.
