Comparison · Backhoe loader

JCB 3CX vs JCB 5CX

The JCB 5CX is about 16% heavier than the JCB 3CX (9,750 vs 8,400 kg), which usually means more stability and lifting capacity but higher transport weight.

The JCB 5CX has about 28% more engine power (87 kW (117 hp) vs 68 kW (91 hp)).

JCB 3CX backhoe loader standing on its stabilisers
JCB JCB 3CX
JCB machine similar to the JCB 5CX (related model may be pictured)
JCB JCB 5CX
Operating weight 8,400 kg (18,500 lb)9,750 kg (21,500 lb)
Engine power 68 kW (91 hp)87 kW (117 hp)
Engine power ≈55–81 kW (74–109 hp), by version≈81–93 kW (109–125 hp)
Max. digging depth ≈5.9 m (19 ft 4 in) with extending dipper—
Engine JCB DieselMax 448—
Loader bucket ≈1.0–1.3 m³ (1.3–1.7 yd³)—
Top speed ≈40 km/h (25 mph)—
Steering —2WS / 4WS / crab
Strengths
  • + Proven design and huge parts availability
  • + Side-shift option for work against walls
  • + Strong resale, especially in Europe and India
  • + Most powerful JCB backhoe
  • + Excellent traction
Watch-outs
  • − Equal-wheel 4WS versions cost considerably more
  • − Some versions have a smaller loader bucket than US rivals
  • − Highest price in the range
Full 3CX reviewFull 5CX review

Specifications are typical figures for standard configurations and may be measured differently by each manufacturer (for example net vs gross power). Always confirm with the manufacturer or dealer. Build another comparison.
